Solartech 125 Watt Mono Solar Panel
Class 1, Division 2 solar compliant panel for 12 Volt applications.
|
Model
|
SPM125M-TS-F
|
|
Series
|
M Series
|
|
Manufacturer
|
Solartech
|
Mechanical
|
Type
|
Monocrystalline
|
|
Dimensions
|
39.9" x 26.3" x 1.38"
|
|
Weight
|
19.84 lbs
|
|
Frame
|
Anodized aluminum
|
|
Connector
|
Junction Box - with 4-1/2" knockout for ease of installation
|
Electrical
|
Watts (STC)
|
125 W
|
|
Max Power Voltage (VMPP)
|
20.1 V
|
|
Max Power Current (IMPP)
|
6.25 A
|
|
Open Circuit Voltage (VOC)
|
24.5 V
|
|
Short Circuit Current (ISC)
|
6.68 A
|
|
Max System Voltage (UL)
|
DC 1000 V
|
Warranty
- 12 Years, 90% output
- 25 years, 80% output
- 5-year limited warranty of materials and worksmanship
Detailed Information
Solartech M-Series Modules
Solartech photovoltaic M-Series Modules are constructed with high efficient monocrystalline solar cells and produce higher output per module than others in it class. This industrial grade module is an industry standard among various industry professionals.
Features
- Accessible junction box with 2 MC4 style 3ft leads for
ease of installation.
- (EVA) with TPT cushions the solar cells within the laminate an ensures the operating characteristics of the solar cells under virtually any climatic condition
- Rigid anodized aluminum frame and low iron tempered glass
- Easily accessible grounding points on all four corners for fast installation
- Proven junction box technology
Applications
- Traffic & Safety
- Federal Government
- Agricultural
- Security
- Telecommunications
- Water and Wastewater
- Weather & Environmental Monitoring
- RV Camper
- Emergency Power
- Telemetry
- SCADA, RTU, GPS
- Marine
- Area Lighting & Sign
- Wi-Fi & Wi=Max
- Fence & Gate
Solartech Solar Panel Ordering Guideline
Example Model No： SPM005P-R-A
1. Solartech Modules Series
2. Cell type:
P： Polycrystal
M: monocrystal
R： Aluminum Frame (equal or less than 30W)
D： Picture Frame (equal or less than 30W)
A： Cable is 3M, no Ring connector(equal or less than 30W)
N： Cable is 1M, no Ring connector(equal or less than 30W)
F： 4 hole J-BOX no cable;not perforated
F4： 4 hole J-BOX +MC4 connector
F3： 4 hole J-BOX +MC3 connector
L1： 4 hole J-BOX no cable;open-hole at left
R1： 4 hole J-BOX no cable;open-hole at right
LR： 4 hole J-BOX no cable;open-hole at right and left
D2： 4 hole J-BOX no cable;two hole at down
TS（N）： normal size (currently just used in SPM080P-TS)
TL： long type size (currently just used in SPM080P-TL)
WP: Application voltage is 24V
S： Small size than normal
|
|
|
|
 |
|
 |
|
|
|
